Sub-pipeline example: Pipeline with environment variables for environments

Source code for this example.

This example extends the example Sub-pipeline with environment variables. The differences are following:

In the task below:

There is two more parameters with names CONNECTION_STRING - mandatory, no default value, and PROD_USER - optional, set default value if it is not passed from the sub-pipeline.

params:
  ...
  - name: CONNECTION_STRING     #it must be set in a sub-pipeline's task params, because it does not have default value
  - name: PROD_USER             #it can be set in a sub-pipeline's task params, if not - used default "not-set-in-task"
    default:
      type: string
      stringVal: not-set-in-task

There are two more environment variables in a step ConnectionString and ProdUser

env:
  ...
  - name: ConnectionString
    value: $(params.CONNECTION_STRING)  #set by parameter CONNECTION_STRING
  - name: ProdUser
    value: $(params.PROD_USER)  #set by parameter PROD_USER

The step script has extended command, to print in addition environment variables, which name contain VAR, Connection or User printenv | grep -E 'VAR|Connection|User'
Task file env-vars-list-task.yaml

apiVersion: tekton.dev/v1
kind: Task
metadata:
  name: env-vars-list
spec:
  params:
    - name: VAR1T                 #it must be set in a sub-pipeline's task params, because it does not have default value
    - name: VAR2T                 #it can be set in a sub-pipeline's task params, if not - used default "not-set-var2-in-task"
      default:
        type: string
        stringVal: not-set-var2-in-task
    - name: VAR3T                 #it can be set in a sub-pipeline's task params, if not - used default "not-set-var3-in-task"
      default:
        type: string
        stringVal: not-set-var3-in-task
    - name: VAR4T                 #it can be set in a sub-pipeline's task params, if not - used default "not-set-var4-in-task"
      default:
        type: string
        stringVal: not-set-var4-in-task
    - name: VAR5T                 #it can be set in a sub-pipeline's task params, if not - used default "not-set-var5-in-task"
      default:
        type: string
        stringVal: not-set-var5-in-task
    - name: CONNECTION_STRING     #it must be set in a sub-pipeline's task params, because it does not have default value
    - name: PROD_USER             #it can be set in a sub-pipeline's task params, if not - used default "not-set-in-task"
      default:
        type: string
        stringVal: not-set-in-task
  steps:
    - name: show-env-vars-list
      image: alpine
      env:
        - name: VAR1example
          value: $(params.VAR1T)  #set by parameter VAR1T
        - name: VAR2example
          value: $(params.VAR2T)  #set by parameter VAR2T
        - name: VAR3example
          value: $(params.VAR3T)  #set by parameter VAR3T
        - name: VAR4example
          value: $(params.VAR4T)  #set by parameter VAR4T
        - name: VAR5example
          value: $(params.VAR5T)  #set by parameter VAR5T
        - name: VAR6example
          value: "value6"         #set explicitly with the value "value6"
        - name: ConnectionString
          value: $(params.CONNECTION_STRING)  #set by parameter CONNECTION_STRING
        - name: ProdUser
          value: $(params.PROD_USER)  #set by parameter PROD_USER
      script: |
        #!/usr/bin/env sh
        printenv | grep -E 'VAR|Connection|User'

The sub-pipeline in addition has:

parameters CONNECTION_STRING - mandatory, no default value, and PROD_USER - optional, set default value if it is not set in the radixconfig.yaml

  params:
    ...
    - name: CONNECTION_STRING  #it must be set in the radixconfig.yaml
    - name: PROD_USER          #it can be set in the radixconfig.yaml, if not - used default empty string
      default:
        type: string
        stringVal: ""

task parameters CONNECTION_STRING - set by CONNECTION_STRING sub-pipeline parameter, and PROD_USER - set by PROD_USER sub-pipeline parameter

params:
  ...
  - name: CONNECTION_STRING #set by parameter CONNECTION_STRING, from the radixconfig.yaml
    value:
      type: string
      stringVal: $(params.CONNECTION_STRING)
  - name: PROD_USER         #set by parameter PROD_USER, from the radixconfig.yaml
    value:
      type: string
      stringVal: $(params.PROD_USER)

Sub-pipeline file pipeline.yaml

apiVersion: tekton.dev/v1
kind: Pipeline
metadata:
  name: pipeline-example-with-env-vars
spec:
  params:
    - name: VAR1               #it must be set in the radixconfig.yaml
    - name: VAR2               #it can be set in the radixconfig.yaml, if not - used default "not-set-var2"
      default:
        type: string
        stringVal: not-set-var2
    - name: VAR3               #it can be set in the radixconfig.yaml, if not - used default "not-set-var3"
      default:
        type: string
        stringVal: not-set-var3
    - name: CONNECTION_STRING  #it must be set in the radixconfig.yaml
    - name: PROD_USER          #it can be set in the radixconfig.yaml, if not - used default empty string
      default:
        type: string
        stringVal: ""
  tasks:
    - name: show-env-vars      #name of the task "env-vars-list" in this pipeline
      params:
        - name: VAR1T          #set by parameter VAR1, from the radixconfig.yaml
          value:
            type: string
            stringVal: $(params.VAR1)
        - name: VAR2T          #set by parameter VAR2, from the radixconfig.yaml or used default "not-set-var2"
          value:
            type: string
            stringVal: $(params.VAR2)
        - name: VAR3T          #set by parameter VAR3, not set in the radixconfig.yaml - used default "not-set-var3"
          value:
            type: string
            stringVal: $(params.VAR3)
        - name: VAR4T          #set explicitly with the value "value4"
          value:
            type: string
            stringVal: value4
        - name: CONNECTION_STRING #set by parameter CONNECTION_STRING, from the radixconfig.yaml
          value:
            type: string
            stringVal: $(params.CONNECTION_STRING)
        - name: PROD_USER         #set by parameter PROD_USER, from the radixconfig.yaml
          value:
            type: string
            stringVal: $(params.PROD_USER)
      taskRef:
        name: env-vars-list    #task name

File structure can be like this:

/
├── tekton/
│   ├── pipeline.yaml
│   └── env-vars-list-task.yaml
└── radixconfig.yaml

The file radixconfig.yaml has two environments dev and prod, with addition field variables within the subPipeline option, which adds or overrides common build variables from the field build.valiables:

apiVersion: radix.equinor.com/v1
kind: RadixApplication
metadata:
  name: radix-sub-pipeline-example
spec:
  build:
    subPipeline:
      variables:
        VAR1: value1     #it must be set, as it is expected by the sub-pipeline
        VAR2: value2     #it can be set, if it does not exist - the sub-pipeline will set default value
        VAR100: value100 #it is not used in the sub-pipeline and its tasks
  environments:
    - name: dev
      build:
        from: pipeline-example-with-env-vars-for-envs
      subPipeline:
        variables:
          VAR1: "val1-for-dev"  #overrides common env-var VAR1 in the "dev" Radix pipeline
          CONNECTION_STRING: "Provider=MySQLProv;Data Source=devDb;" #overrides common env-var CONNECTION_STRING in the "dev" custom sub-pipeline
    - name: prod
      build:
        from: release
      subPipeline:
        variables:
          PROD_USER: "prod-user" #it exists only in prod environment
          CONNECTION_STRING: "Provider=MySQLProv;Data Source=prodDb;" #overrides common env-var CONNECTION_STRING in the "prod" custom sub-pipeline
  components:
    - name: frontend
      src: frontend
      ports:
        - name: http
          port: 8001
      publicPort: http
  dnsAppAlias:
    environment: dev
    component: frontend

common valiables: VAR1, VAR2 and VAR100, they can be used in all environments.

VAR1 - mandatory variable, it is expected by the sub-pipeline.
VAR2 - optional
VAR100 - unnecessary variable, not used in the sub-pipeline, it will be not passed to the sub-pipeline parameters.

spec:
  build:
    subPipeline:
      variables:
        VAR1: value1     #it must be set, as it is expected by the sub-pipeline
        VAR2: value2     #it can be set, if it does not exist - the sub-pipeline will set default value
        VAR100: value100 #it is not used in the sub-pipeline and its tasks

dev build environment:

Common variable VAR1 is overridden to be passed to the sub-pipeline parameter VAR1 with the value "val1-for-dev".
New variable CONNECTION_STRING contains dev-environment specific connection string "Provider=MySQLProv;Data Source=devDb;"

environments:
  - name: dev
    build:
      from: pipeline-example-with-env-vars-for-envs
    subPipeline:
      variables:
        VAR1: "val1-for-dev"  #overrides common env-var VAR1 in the "dev" external pipeline
        CONNECTION_STRING: "Provider=MySQLProv;Data Source=devDb;" #overrides common env-var CONNECTION_STRING in the "dev" custom sub-pipeline

prod build environment:

New variable PROD_USER contains prod-environment specific user name "prod-user".
New variable CONNECTION_STRING contains prod-environment specific connection string "Provider=MySQLProv;Data Source=prodDb;"

environments:
  - name: prod
    build:
      from: release
    subPipeline:
      variables:
        PROD_USER: "prod-user" #it exists only in prod environment
        CONNECTION_STRING: "Provider=MySQLProv;Data Source=prodDb;" #overrides common env-var CONNECTION_STRING in the "prod" custom sub-pipeline

tip

Common variable CONNECTION_STRING does not exists, as it is always different in each environment

This sub-pipeline runs the task show-env-vars (which reference to the task env-vars-list described in the file env-vars-list-task.yaml), which has one step, as described above. This step run a script, printing environment variables, which names contain text VAR

#!/usr/bin/env sh
printenv | grep -E 'VAR|Connection|User'

Commit changes in the repository. Look at the details of a started Radix pipeline job (if the Radix app is connected to the GitHub WebHook, otherwise - start a job manually).
Sub-pipelines and tasks lists are similar to the example Sub-pipeline with environment variables.
Navigate to the task (click on its name in the table row)
The sub-pipeline task overview page shows a table with a list of this task's steps - in this example it is one step "show-env-vars-list", the step status and log.
- Step for the sub-pipeline in the dev environment. The variable ConnectionString contains "Data Source=devDb", VAR1example has overridden common value "val1-for-dev", ProdUser has no value The log shows environment variables of the step container:
```
ConnectionString=Provider=MySQLProv;Data Source=devDb;
VAR1example=val1-for-dev
VAR2example=value2
VAR3example=not-set-var3
VAR4example=value4
VAR5example=not-set-var5-in-task
VAR6example=value6
ProdUser=
```
- VAR6example - this variable is not defined in the sub-pipeline's task params and task's params, it is set implicitly in the task step's field env
```
  steps:
    - env:
      - name: VAR6example
        value: "value6"
```
- Step for the sub-pipeline in the prod environment. The variable ConnectionString contains "Data Source=prodDb", VAR1example has common value "value1", ProdUser has value "value6" The log shows environment variables of the step container:
```
ConnectionString=Provider=MySQLProv;Data Source=prodDb;
VAR1example=value1
VAR2example=value2
VAR3example=not-set-var3
VAR4example=value4
VAR5example=not-set-var5-in-task
VAR6example=value6
ProdUser=prod-user
```
